Sinsim Brand Schiffli embroidery machine
Champion Family
Bangladesh Exclusive
Sole Agent
B2, Level: 3, Plot: 32 Road: 01 (Jasimuddin Avenue) Sector: 03, Uttara, Dhaka, Bangladesh 1230 Dhaka, Bangladesh
Machine Specification
9 Color
Needles
330mm
Head interval
1500
Maximum speed
4.02 kw
Power consumption
Dahao X-98 Control System
Control System
330*660*800mm
Embroidery Area
Other Specification
| Tension Base | Intelligent thread break detect | Main Shaft Motor | 3.1-3.7 KW Servo Motor x 1pc |
| Upper Thread Holding Device | Automatic keep locked thread device | Embroidery Speed: 1500 (1350 and 1500 rpm optional) | 250-1500RPM |
| Auto Lubrication | Yes | X/Y Motor | 1.5KW Servo Motor X1pcs, Y1pcs |
| Memory | 200,0000 stitches, 200pcs design | Input Mode | U DISK & wifi |
| Power consumption | 1.5KW-5KW | Design Format | Wilcom & Dahao Supported |
| Head Structure | Double crank, Double Cam double lever, pressure foot and needle bar drive independently | Head Lock System | Solenoid jump or Motor jump |
| Machine Color | Silver | Embroidery trimming | Auto Trimming |
| Color Change | Screw rod automatic color System | Combination Embroidery Function | Customized |
Certificate
highlights
Mechine
Description
Schiffli embroidery machine
1-300 Customized
The SINSIM high-speed Flat embroidery machine is specifically designed to minimize fabric fluttering, a common challenge encountered during embroidery. This innovative technology ensures exceptional stitch quality and precision, particularly when working with a variety of materials such as thick fabrics, delicate fabrics, leather and folded material.
The SINSIM high-speed Flat embroidery machine is specifically designed to minimize fabric fluttering, a common challenge encountered during embroidery. This innovative technology ensures exceptional stitch quality and precision, particularly when working with a variety of materials such as thick fabrics, delicate fabrics, leather and folded material.
Mechine
features
Core Functionality
- Multi-needle embroidery capability
- Automatic thread trimming
- Adjustable stitch density and length
- High-speed stitching
Core Functionality
- Multi-needle embroidery capability
- Automatic thread trimming
- Adjustable stitch density and length
- High-speed stitching
Core Functionality
- Multi-needle embroidery capability
- Automatic thread trimming
- Adjustable stitch density and length
- High-speed stitching
Core Functionality
- Multi-needle embroidery capability
- Automatic thread trimming
- Adjustable stitch density and length
- High-speed stitching
